Vertical Induction Electric Motor YL

Vertical electric motor is also called vertical motor or asynchronous motor.

● Frequency: 50/60 Hz;
● Frame size: H315mm-H1000mm;
● Power range: 250kW~10000kW;
● Number of poles: 2P~12P;
● Rated voltage: 6000V, 10000V and various special voltages;
● Insulation class: Class F;
● Protection class: IP23;
● Installation method: IMV1;
● Cooling method: IC01;

● 20 Years’ Experience;
● 65,000 ㎡ Factory;
● ISO 9001:2016, ISO 14001:2015, ISO 45001:2020;
● OEM/ODM Accept.

Availability:

Quantity:



Inquire Add to Basket

Product Description

We're professional vertical electric motor manufacturers and suppliers in China, to buy or wholesale vertical motor from our factory. For quotation or if you have any questions, contact us now for customized asynchronous motor and price.

Product features

● high power index;

● low noise and vibration;

● high reliability;

● easy use;

● installation and maintenance.

Product application

The motor can be used to drive vertical machinery such as vertical water pumps, but it does not bear additional axial force other than the weight of the motor rotor.

Technical Parameters

Technical data (guaranteed values) of YL series 6KV vertical asynchronous motors are shown

Model	Rated power (KW)	Rated current (A)	Rated speed (r/min )	Power factor cosΦ	Maximum torque/Rated torque	Locked-rotor moment/Rated torque	Locked-rotor current/Rated current	Moment of inertia /Electric machine kg. m²	Moment of inertia/load kg. m²
YL355-4	185	22.8	1477	0.84	1.8	0.8	6.5	5	64.0
YL355-4	200	24.6	1477	0.84	1.8	0.8	6.5	5.2	70
YL355-4	220	26.7	1477	0.85	1.8	0.8	6.5	5.5	76
YL355-4	250	30.3	1478	0.85	2	0.8	6.5	6	82
YL355-4	280	33.5	1478	0.86	1.8	0.8	6.5	6	95
YL355-4	315	37.7	1478	0.06	1.8	0.8	6.5	8	106
YL400-4	355	42.3	1485	0.86	1.8	0.8	6.5	13	88
YL400-4	400	47.6	1486	0.84	1.8	0.8	6.5	14	98
YL400-4	450	53.5	1485	0.86	1.8	0.8	6.5	15	108
YL400-4	500	58.6	1485	0.87	1.8	0.8	6.5	17	119
YL400-4	560	65.5	1485	0.87	1.8	0.8	6.5	18	131
YL450-4	630	73.5	1485	0.87	1.8	0.8	6.5	19	145
YL450-4	710	82.7	1485	0.87	1.8	0.8	6.5	21	181
YL450-4	800	93.0	1486	0.87	1.8	0.8	6.5	22	178
YL450-4	900	104.6	1487	0.87	1.8	0.8	6.5	24	197
YL500-4	1000	116.1	1485	0.87	2	0.7	8.5	29	214
YL500-4	1120	128.4	1485	0.88	1.8	0.7	6.5	31	235
YL500-4	1250	143.1	1485	0.88	1.8	0.7	6.5	35	256
YL500-4	1400	160.1	1484	0.88	1.8	0.7	6.5	37	280
YL560-4	1000	180.8	1480	0.89	1.8	0.6	6.5	57	310
YL560-4	1800	203.1	1488	0.89	1.8	0.6	6.5	61	240
YL560-4	2000	225.5	1488	0.89	1.8	0.6	6.5	68	167
YL630-4	2240	252.3	1408	0.89	1.8	0.6	6.5	107	397
YL630-4	2500	281.3	1488	0.89	1.8	0.6	8.5	113	427
YL630-4	2800	314.7	1488	0.89	1.0	0.6	6.5	5.5	462
YL355-6	185	23.7	987	0.81	1.8	0.8	6.0	10	167
YL355-6	200	25.6	987	0.81	1.8	0.8	6.0	10	187
YL355-6	220	27.8	987	0.82	1.8	0.8	6.0	11	209
YL355-6	250	31.4	987	0.82	1.8	0.8	6.0	11	234
YL400-6	280	34.7	988	0.83	1.8	0.8	6.0	18	259
YL400-6	315	39.0	988	0.83	1.8	0.8	0.0	19	288
YL400-6	355	43.8	988	0.83	1.8	0.8	6.0	20	321
YL400-6	400	49.3	988	0.83	1.8	0.8	6.0	21	358
YL450-6	450	24.7	984	0.84	1.8	0.8	6.0	28	197
YL450-6	500	59.9	944	0.85	1.8	0.8	6.0	30	436
YL450-6	560	66.9	988	0.85	1.8	0.8	6.0	31	484
YL450-6	630	75.2	989	0.85	1.8	0.8	6.0	33	535
YL500-6	710	84.6	990	0.85	1.8	0.7	6.0	43	595
YL500-6	800	95.3	989	0.85	1.8	0.7	6.0	44	660
YL500-6	900	107.0	989	0.85	1.8	0.7	6.0	50	730
YL500-6	1000	118.8	989	0.85	1.8	0.7	8.0	52	709
YL560-6	1120	131.4	990	0.86	1.8	0.7	6.5	69	731
YL560-6	1250	146.5	990	0.86	1.8	0.7	6.5	77	790
YL560-6	1400	163.9	990	0.86	1.8	0.7	6.5	82	868
YL630-6	1600	187.1	991	0.86	1.8	0.7	6.5	125	935
YL630-6	1800	210.2	991	0.86	1.8	0.7	6.5	134	1038
YL630-6	2000	233.3	991	0.86	1.8	0.7	6.5	143	1129
YL400-8	185	25.0	741	0.77	1.8	0.8	5.5	18	382
YL400-8	200	26.6	741	0.78	1.8	0.8	5.5	20	401
YL400-8	220	29.2	741	0.78	1.8	0.8	5.5	22	421
YL400-8	250	32.7	741	0.79	1.8	0.8	5.5	23	474
YL400-8	280	36.6	741	0.79	1.8	0.8	5.5	24	526
YL450-8	315	40.6	742	0.80	1.8	0.8	5.5	30	585
YL450-8	355	45.7	742	0.8	1.8	0.8	5.5	32	652
YL450-8	400	51.3	742	0.80	1.8	0.8	5.5	34	727
YL450-8	450	57.0	742	0.81	1.8	0.8	5.5	37	809
YL500-8	500	63.0	742	0.81	1.8	0.8	5.5	47	889
YL500-8	560	69.6	742	0.82	1.8	0.8	5.5	50	983
YL500-8	630	78.2	743	0.82	1.8	0.8	5.5	55	1095
YL500-8	710	88.1	744	0.82	1.8	0.8	5.5	58	1215
YL560-8	800	96.8	743	0.84	1.8	0.7	6.0	88	1352
YL560-8	900	108.8	743	0.84	1.8	0.7	6.0	97	1501
YL560-8	1000	120.7	743	0.84	1.8	0.7	6.0	103	1601
YL630-8	1120	135.1	744	0.84	1.8	0.7	6.0	136	1808
YL630-8	1250	150.6	744	0.84	1.8	0.7	6.0	143	1987
YL630-8	1400	168.5	744	0.84	1.8	0.7	6.0	156	2190
YL630-8	1600	192.3	744	0.84	1.8	0.7	6.0	167	2455
YL400-10	185	25.9	593	0.75	1.8	0.8	5.5	28	572
YL400-10	200	27.9	593	0.75	1.8	0.8	5.5	29	644
YL450-10	220	29.9	592	0.77	2	0.8	5.5	30	725
YL450-10	250	33.4	592	0.78	2	0.8	5.5	31	816
YL450-10	280	37.3	592	0.78	1.8	0.8	5.5	33	906
YL450-10	315	41.4	592	0.79	1.8	0.8	5.5	35	1007
YL450-10	355	46.6	592	0.79	1.8	0.8	5.5	39	1126
YL500-10	400	51.6	592	0.80	1.8	0.8	5.5	55	1255
YL500-10	450	58.0	593	0.80	1.8	0.8	5.5	57	1395
YL500-10	500	64.3	594	0.80	1.8	0.8	5.5	64	1534
YL500-10	560	71.9	594	0.8	1.8	0.8	5.5	69	1896
YL500-10	630	80.8	595	0.80	1.8	0.8	6.5	73	10.2
YL560-10	710	88.6	593	0.82	1.8	0.7	6.0	107	2110
YL560-10	800	99.7	593	0.82	1.8	0.7	6.0	113	2340
YL560-10	900	112.0	593	0.82	1.8	0.7	6.0	123	2598
YL630-10	1000	124.3	594	0.82	1.8	0.7	6.0	152	2856
YL630-10	1120	138.9	594	0.82	1.8	0.7	6.0	102	3155
YL630-10	1250	154.7	594	0.82	1.8	0.7	6.0	177	3473
YL630-10	1400	173.1	594	0.82	1.8	0.7	6.0	194	3832
YL450-12	185	27.2	494	0.72	1.8	0.8	5.5	38	938
YL450-12	200	29.3	494	0.72	1.8	0.8	5.5	40	1028
YL450-12	220	31.7	494	0.73	1.8	0.8	5.5	42	1127
YL450-12	250	35.9	494	0.73	1.8	0.8	5.5	44	1236
YL500-12	280	39.3	493	0.74	1.8	0.8	5.5	52	1416
YL500-12	315	43.6	493	0.75	1.8	0.8	5.5	56	1575
YL500-12	355	49.0	494	0.75	1.8	0.8	5.5	61	1755
YL500-12	400	55.0	494	0.75	1.8	0.8	5.5	66	1964
YL500-12	450	61.8	495	0.75	1.8	0.8	5.5	74	2184
YL560-12	500	65.0	495	0.79	1.8	0.7	8.0	104	2400
YL560-12	560	72.7	495	0.79	1.8	0.7	6.0	116	2660
YL560-12	630	81.7	495	0.79	1.8	0.7	6.0	122	2960
YL630-12	710	92.0	495	0.79	1.8	0.7	6.0	174	3295
YL630-12	800	103.4	495	0.79	1.8	0.7	6.0	186	3673
YL000-12	900	116.2	495	0.79	1.8	0.7	6.0	204	4000
YL630-12	1000	129.0	495	0.79	1.8	0.7	6.0	218	4530

Technical data (guaranteed values) of YL series 10kV vertical asynchronous motors are shown

Model	Rated power(kW)	Rated current(A)	Rated speed (r/min)	Efficiency(%)	Power factor cosφ	Maximum torque/rated torque Mmax/Mn	Blocked torque/rated torqueMst/Mn	Lock current/rated current	Moment of inertia /J motor kg. m2	Moment of inertia /J load kg.m2
Y450-2	355	25.1	2076	93.8	0.87	1.8	0.6	7	6.05	11.4
Y450-2	400	20.2	2978	94.1	0.87	1.8	0.6	7	12.1	16.0
Y450-2	450	31.7	2976	94.2	0.87	1.8	0.6	7	12.1	18.7
Y450-2	500	35.2	2977	94.4	0.87	1.8	0.6	7	12.65	19.0
Y450-2	560	39.3	2977	94.5	0.87	1.8	0.6	7	13.2	19.8
Y450-2	400	44.2	2989	94.6	0.87	1.8	0.6	7	20.9	20.2
Y500-2	710	49.2	2989	94.7	0.88	1.8	0.6	7	22.0	21.0
Y500-2	300	55.4	2987	94.8	0.88	1.8	0.6	7	23.1	22.9
Y500-2	900	62.2	2987	94.9	0.88	1.8	0.6	7	24.2	24.3
Y500-2	1000	69.1	2985	95.0	0.88	1.8	0.6	7	31.9	25.1
Y500-2	1120	77.2	2986	95.2	0.88	1.8	0.6	7	34.1	27.9
Y560-2	1250	85.0	2986	95.4	0.89	1.8	0.6	7	37.4	32.6
Y560-2	1400	95.1	2988	95.5	0.89	1.8	0.6	7	39.6	35.4
Y560-2	1600	108.6	2985	95.6	0.89	1.8	0.6	7	45.1	50.9
Y630-2	1800	120.7	2987	95.7	0.9	1.8	0.6	7	50.6	54.4
Y630-2	2000	134.0	2985	95.8	0.9	1.8	0.6	7	53.9	61.1
Y630-2	2240	149.7	2987	96.0	0.9	1.8	0.6	7	57.2	67.8
Y450-4	355	25.5	1486	93.3	0.86	1.8	0.7	7	16.5	88.5
Y450-4	400	28.7	1487	93.5	0.86	1.8	0.7	7	16.5	93.5
Y450-4	450	32.2	1485	93.9	0.86	1.8	0.7	7	17.6	103.4
Y450-4	500	35.7	1486	94	0.86	1.8	0.7	7	18.7	104.3
Y450-4	560	39.9	1489	94.2	0.86	1.8	0.7	7	27.5	117.5
Y450-4	630	44.8	1490	94.4	1.86	1.8	0.7	7	27.5	131.5
Y500-4	710	49.6	1490	95	0.87	1.8	0.7	7	30.8	139.2
Y500-4	800	55.8	1489	95.1	0.87	1.8	0.7	7	30.8	149.2
Y500-4	900	62.0	1489	95.2	0.88	1.8	0.7	7	33	172.0
Y500-4	1000	68.8	1489	95.3	0.88	1.8	0.7	7	47.3	185.7
Y500-4	1120	77.0	1490	95.4	0.88	1.8	0.7	7	50.6	210.4
Y560-4	1250	84.9	1489	95.5	0.88	1.8	0.7	7	50.6	250.4
Y560-4	1400	94.9	1490	95.7	0.89	1.8	0.7	7	59.4	279.6
Y560-4	1600	108.3	1493	95.8	0.89	1.8	0.7	7	97.9	331.1
Y630-4	1800	121.8	1492	95.9	0.89	1.8	0.6	7	97.9	376.1
Y630-4	2000	135.2	1493	96.0	0.89	1.8	0.6	7	103.4	420.6
Y630-4	2240	151.2	1493	96.1	0.89	1.8	0.6	7	114.4	449.6
Y450-6	315	23.9	991	92.8	0.82	1.8	0.7	6	24.2	236.8
Y450-6	355	26.5	991	93.1	0.83	1.8	0.7	6	37.4	241.6
Y450-6	400	29.8	991	93.3	0.83	1.8	0.7	6	40.7	276.3
Y450-6	450	33.5	902	93.6	0.83	1.8	0.7	6	44	325.0
Y500-6	500	37.0	990	93.9	0.83	1.8	0.7	6	44	295.0
Y500-6	560	40.9	991	94.1	0.84	1.8	0.7	6	47.3	326.7
Y500-6	630	45.9	991	94.4	0.84	1.8	0.7	6	50.6	370.4
Y500-6	710	51.6	993	94.6	0.84	1.8	0.7	6	64.9	414.1
Y500-6	800	58.4	993	94.7	0.84	1.8	0.7	6	75.9	453.1
Y560-6	900	54.4	994	94.9	0.85	1.8	0.7	6	80.3	492.7
Y560-6	1000	71.4	993	95.1	0.85	1.5	0.7	6	80.3	532.7
Y560-6	1120	79.8	995	95.3	0.85	1.8	0.7	6	113.3	570.7
V560-6	1250	88.0	995	95.4	0.86	1.8	0.7	6	124.3	610.7
Y630-6	1400	98.2	995	95.7	0.86	1.8	0.6	6	133.1	680.9
Y600-6	1600	112.1	995	95.8	0.86	1.8	0.6	6	147.4	967.6
Y630-6	1800	126.0	995	95.9	0.86	1.8	0.6	6	154.6	1085.9
Y500-8	315	25.5	739	92.8	0.77	1.8	0.7	6	47.3	411.7
Y500-8	355	28.6	739	93.1	0.77	1.8	0.7	6	49.5	440.5
Y500-8	400	31.8	738	93.2	0.78	1.8	0.7	6	49.5	475.5
Y500-8	450	35.7	738	93.4	0.78	1.8	0.7	6	55	505
Y500-8	500	39.0	739	93.8	0.79	1.8	0.7	6	58.3	534.7
Y500-8	560	43.6	744	93.9	0.79	1.8	0.7	6	85.8	552.2
Y560-8	630	47.0	743	94.4	0.82	1.8	0.7	6	91.3	611.7
Y560-8	710	52.8	743	94.6	0.82	1.8	0.7	6	99	701
Y560-8	800	59.5	744	94.7	0.82	1.8	0.7	6	99	791
Y560-8	900	66.8	744	94.8	0.82	1.8	0.7	6	141.9	856.1
Y630-8	1000	73.2	744	95.0	0.83	1.8	0.7	6	155.1	960.9
Y630-8	1120	81.8	744	95.2	0.83	1.8	0.7	6	177.1	1063.9
Y63048	1250	91.2	745	95.3	0.83	1.8	0.7	6	192.5	1192.5
Y500-10	280	23.6	590	92.4	0.74	1.8	0.7	6	53.9	993.1
Y500-10	315	26.5	590	92.6	0.74	1.8	0.7	5.5	57.2	1134.8
Y500-10	355	29.4	590	92.8	0.75	1.8	0.7	5.5	57	1224.8
Y500-10	400	33.1	590	93.0	0.75	1.8	0.7	5.5	63.8	1284.2
Y560-10	450	36.2	590	93.2	0.77	1.8	0.7	6	67.1	1333.9
Y560-10	500	40.1	593	93.4	0.77	1.8	0.7	6	107.8	1360.2
Y560-10	560	44.3	592	93.5	0.78	1.8	0.7	6	107.8	1410.2
Y560-10	630	49.8	593	93.7	0.78	1.8	0.7	6	117.7	1499.3
Y560-10	710	56.0	593	93.9	0.78	1.8	0.7	6	130.9	1658.1
Y630-10	800	61.2	594	94.3	0.8	1.8	0.7	6	184.8	2063.2
Y630-10	900	68.7	595	94.5	0.8	1.8	0.7	9	194.7	2362.3
7630-10	1000	76.3	593	94.0	0.8	1.8	0.7	6	212.3	2420.7
Y630-10	1120	85.4	593	94.7	0.8	1.8	0.7	6	224.4	2389.6
Y560-12	315	27.0	494	92.3	0.73	1.8	0.7	6	104.5	1000.5
7560-12	355	30.4	494	92.5	0.73	1.8	0.7	6	114.4	1179.6
Y560-12	400	34.1	494	92.7	0.73	1.8	0.7	6	121.0	1279.0
Y560-12	450	38.3	494	92.9	0.73	1.8	0.7	6	133.1	1407.9
Y560-12	500	42.4	493	93.2	0.73	1.8	0.7	6	133.1	1657.8
Y630-12	560	46.7	492	93.5	0.74	1.8	0.7	6	183.7	2073.3
Y630-12	650	52.5	493	93.7	0.74	1.8	0.7	6	201.3	2921.7
Y630-12	710	59.0	493	93.9	0.74	1.8	0.7	6	215.6	3130.4
Y630-12	300	66.2	492	94.4	0.74	1.8	0.7	6	227.7	3199.3

Production environment

Vertical electric motor Manufacturer

As one of China professional large electric motor manufacturers, we focus on providing high-quality vertical electric motor and excellent service since 2003. We are a professional manufacturer and factory of 65,000 M² which mainly produce hv motors, ex proof motor, pmsm motor products for around 20 years’ experience. We provide you with large electric motors wholesale, customization, design, packaging, industry solutions and OEM & ODM service.

If you have any questions about vertical electric motor, vertical motor, asynchronous motor,vertical induction motor, please don't hesitate to contact us at any time. We will provide detailed information and technical support about the features, specifications, solutions and customization options of hv motors, ex proof motor, pmsm motor... Welcome you to visit our factory!
