Wound Induction Motor YR

Wound induction motor is also called motor wound or wound round motor.

● Frequency: 50/60 Hz;
● Frame size: H355mm-H1000mm;
● Power range: 220kW～5600kW;
● Number of poles: 4P～12P;
● Rated voltage: 6000V, 10000V and various special voltages;
● Insulation grade: Class F;
● Protection grade: IP23;
● Installation method: IMB3;
● Cooling method: IC01;

● 20 Years’ Experience;
● 65,000 M2 Factory;
● ISO 9001:2016, ISO 14001:2015, ISO 45001:2020;
● OEM/ODM Accept.

Availability:

Quantity:



Inquire Add to Basket

Product Description

We're professional wound induction motor manufacturers and suppliers in China, to buy or wholesale motor wound from our factory. For quotation or if you have any questions, contact us now for customized wound round motor and price.

Product features

● high power index;

● low noise and vibration;

● high reliability;

● easy use;

● installation and maintenance.

Product application

The motor can be used to drive various general machinery such as compressors, water pumps, crushers, cutting machine tools, transportation machinery and other mechanical equipment, and can be used as prime movers in various industrial and mining enterprises such as mines, machinery, metallurgy, petroleum, chemical industry, power stations, etc. The motor used to drive blowers, coal mills, rolling mills, and winches should provide relevant technical information when ordering, and a technical agreement should be signed as the basis for the special design of the motor to ensure the reliable operation of the motor.

Technical Parameters

YR series 6kV three-phase asynchronous motor technical data (guaranteed value) see Table 1

Model number	Rated power (kW)	Stator current (A)	Rated speed (r/min)	efficiency (%)	Power factor cosφ	High torque/rated torque Mmax/Min	Rotor voltage U2(V)	Rotor current l2(A)	Moment of inertia/motor kg. m²	Weight (kg)
YR355-4	220	27.5	1470	92.7	0.83	1.8	314	437.8	7.7	2420
YR355-4	250	30.8	1471	93.0	0.84	1.8	342	455.2	8.8	2519
YR355-4	280	34.5	1472	93.1	0.84	1.8	376	461.8	9.9	2607
YR400-4	315	38.3	1473	93.2	0.85	1.8	376	519	12.1	2893
YR400-4	355	43.1	1474	93.3	0.85	1.8	418	524	13.2	2981
YR400-4	400	48.4	1473	93.5	0.85	1.8	438	565	14.3	3069
YR400-4	450	54.4	1475	93.7	0.85	1.8	493	562	15.4	3201
YR400-4	500	60.3	1476	93.9	0.85	1.8	537	572	16.5	3278
YR450-4	560	67.3	1482	94.2	0.85	1.8	672	530	18.7	3993
YR450-4	630	74.6	1480	94.5	0.86	1.8	667	582.3	20.9	4136
YR450-4	710	84.0	1481	94.6	0.86	1.8	759	596	22.0	4246
YR450-4	800	93.4	1482	94.7	0.87	1.8	914	534	23.1	4422
YR500-4	900	105.0	1482	94.8	0.87	1.8	794	694	30.8	4851
YR500-4	1000	116.6	1484	94.9	0.87	1.8	894	682	33.0	4994
YR500-4	1120	130.4	1486	95.0	0.87	1.8	1022	666	35.2	5181
YR500-4	1250	145.4	1484	95.1	0.87	1.8	1052	723	37.4	5357
YR560-4	1400	162.7	1484	95.2	0.87	1.8	1050	810	62.7	7007
YR560-4	1600	185.7	484	95.3	0.87	1.8	1130	862	66.0	7106
YR560-4	1800	208.7	1484	95.4	0.87	1.8	1225	894	71.5	7414
YR630-4	2000	231.6	1486	95.5	0.87	1.8	1379	904	99.0	8987
YR630-4	2240	259.2	1487	95.6	0.87	1.8	1517	918	106.7	9427
YR630-4	2500	288.9	1487	95.7	0.87	1.8	1643	948	113.3	9867
YR400-6	220	28.3	979	92.5	0.81	1.8	416	328	15.4	2871
YR400-6	250	31.6	980	92.7	0.82	1.8	468	330	16.5	2970
YR400-6	280	35.4	979	92.8	0.82	1.8	468	374	17.6	3069
YR400-6	315	39.7	982	93.0	0.82	1.8	561	346	19.8	3190
YR400-6	355	44.7	982	93.2	0.82	1.8	624	350	20.9	3289
YR450-6	400	49.6	985	93.5	0.83	1.8	694	354	27.5	3938
YR450-6	450	55.1	983	93.6	0.84	1.8	714	388	29.7	4059
YR450-6	500	61.1	984	93.8	0.84	1.8	792	387	30.8	4290
YR450-6	560	68.2	986	94.0	0.84	1.8	891	384	33.0	4345
YR500-6	630	75.6	984	94.3	0.85	1.8	682	573	45.1	4565
YR500-6	710	85.1	985	94.5	0.85	1.8	748	587	47.3	4708
YR500-6	800	95.6	986	94.7	0.85	1.8	830	591	52.8	4873
YR500-6	900	107.5	985	94.8	0.85	1.8	896	621	56.1	5038
YR560-6	1000	119.2	986	95.0	0.85	1.8	912	701	69.3	6380
YR560-6	1120	133.3	987	95.1	0.85	1.8	1020	696	77.0	6666
YR560-6	1250	148.6	987	95.2	0.85	1.8	1118	712	81.4	6853
YR630-6	1400	166.3	988	95.3	0.85	1.8	836	1072	114.4	7788
YR630-6	1600	189.9	989	95.4	0.85	1.8	920	1114	117.7	8063
YR630-6	1800	213.4	989	95.5	0.85	1.8	1022	1126	133.1	8338
YR400-8	220	29.4	734	92.2	0.78	1.8	568	237	22.0	2860
YR400-8	250	33.4	733	923.0	0.78	1.8	567	270	23.1	2959
YR400-8	280	36.9	732	92.5	0.79	1.8	012	282	24.2	3025
YR450-8	315	40.9	733	92.6	0.80	1.8	572	341	29.7	3751
YR450-8	355	46.1	733	92.7	0.80	1.8	620	354	31.9	3072
YR450-8	400	51.1	732	93.0	0.80	1.8	677	365	34.1	3960
YR450-8	450	57.4	734	93.2	0.81	1.8	737	375	37.4	4103
YR500-8	500	63.5	737	93.5	0.81	1.8	706	431	47.3	4565
YR500-8	560	71.1	737	93.7	0.81	1.8	777	444	49.5	4686
YR500-8	630	79.7	738	93.9	0.81	1.8	863	449	55.0	4862
YR500-8	710	89.7	737	94.0	0.81	1.8	927	473	58.3	5027
YR560-8	800	100.9	738	94.2	0.81	1.8	929	529	88.0	6118
YR560-8	900	113.4	739	94.3	0.81	18.0	1068	519	96.8	6358
YR560-8	1000	125.8	738	94.4	0.81	1.8	1151	536	103.4	6600
YR630-8	1120	140.8	741	94.5	0.81	1.8	1149	596	136.4	7799
YR630-8	1250	157.0	741	14.6	0.81	1.8	1245	614	143.0	3140
YR630-8	1400	175.6	741	94.7	0.81	1.8	1358	531	156.2	8481
YR450-10	220	30.1	584	91.3	0.77	1.8	563	242	29.7	3641
YR450-10	250	34.5	584	91.5	0.77	1.8	610	254	33.0	3751
YR450-10	280	37.6	584	91.8	0.78	1.8	664	261	35.2	3751
YR450-10	315	42.3	584	91.9	0.78	1.8	732	266	38.5	3949
YR450-10	355	47.6	585	92.1	0.78	1.8	813	270	40.7	4092
YR500-10	400	53.2	588	92.8	0.78	1.8	732	337	55.0	4521
YR500-10	450	59.6	588	93.1	0.78	1.8	700	503	57.2	4642
YR500-10	500	65.3	588	93.3	0.79	1.8	855	362	83.8	4829
YR500-10	560	73.0	588	93.5	0.79	1.8	918	379	68.2	4994
YR560-10	630	81.0	589	93.6	0.80	1.8	979	424	94.6	6127
YR560-10	710	91.1	590	93.7	0.80	1.8	1058	417	104.5	6358
YR560-10	800	102.6	590	93.8	0.80	1.8	1204	437	111.1	6578
YR630-10	900	115.3	591	93.9	0.80	1.8	1143	483	151.8	7799
YR630-10	1000	127.8	591	94.1	0.80	1.8	1239	490	161.7	8140
YR630-10	1120	143.0	591	94.2	0.80	1.8	1351	509	177.1	8481
YR450-12	220	32.5	455	90.4	0.72	1.8	498	274	41.8	3938
YR450-12	250	36.5	489	91.5	0.72	1.8	568	271	46.2	4081
YR500-12	280	40.3	487	94.7	0.73	1.8	519	350	51.7	4345
YR500-12	315	44.5	487	92.0	0.74	1.8	593	342	55	4477
YR500-12	355	49.5	487	92.1	0.75	1.8	692	327	60.5	4631
YR500-12	400	55.6	488	92.3	0.75	1.8	692	375	66	4785
YR560-12	450	60.8	487	92.6	0.77	1.8	822	345	102.3	5918
YR560-12	500	67.4	489	927.0	0.77	1.8	923	337	107.8	0094
YR560-12	560	75.4	490	92.8	0.77	1.8	1057	329	115.6	6303
YR560-12	630	84.7	491	92.9	0.77	1.8	1233	314	132	6512
YR630-12	710	95.4	491	93.0	0.77	1.8	1204	383	174	7711
YR630-12	800	107.4	491	93.1	0.77	1.8	1305	399	185.9	8041
YR630-12	900	120.7	491	93.2	0.77	1.8	1423	412	203.5	8371

Model	Rated power kW	Rated current A	At rated load		Synchronous speed r/min	Maximum torque/rated torque (Standard value)	weight kg
Model	Rated power kW	Rated current A	Efficiency %	Power factor COSφ	Synchronous speed r/min	Maximum torque/rated torque (Standard value)	weight kg
YR710-4	2800	324	95.8	0.87	1500	1.8	11500
YR710-4	3150	364	95.9	0.87	1500	1.8	12000
YR710-4	3550	409	96.0	0.87	1500	1.8	12500
YR710-4	4000	461	96.1	0.87	1500	1.8	13000
YR800-4	4500	518	96.2	0.87	1500	1.8	14500
YR800-4	5000	575	98.3	0.87	1500	1.8	15200
YR800-4	5600	666	96.4	0.87	1500	1.8	16000
YR710-6	2000	237	95.5	0.85	1000	1.8	11500
YR710-6	2240	200	95.6	0.85	1000	1.8	10000
YR710-6	2500	296	95.7	0.85	1000	1.8	12500
YR710-6	2800	332	95.7	0.85	1000	1.8	13000
YR800-6	3150	373	95.8	0.85	1000	1.8	14500
YR800-6	3550	420	95.9	0.85	1000	1.8	15000
YR800-6	4000	472	96.0	0.85	1000	1.8	15500
YR800-6	4500	531	96.1	0.85	1000	1.8	16000
YR710-8	1800	220	95.0	0.83	750	1.8	11500
YR710-8	2000	244	95.1	0.83	750	1.8	12000
YR710-8	2240	273	95.2	0.83	750	1.8	10000
YR800-8	2500	305	95.3	0.83	750	1.8	14500
YR800-8	2800	341	95.4	0.83	750	1.8	15200
YR800-8	3150	378	95.5	0.84	750	1.8	16000
YR900-8	3550	426	95.6	0.84	750	1.8	17500
YR900-8	4000	479	95.7	0.84	750	1.8	18000
YR900-8	4500	539	95.5	0.54	750	1.8	15000
YR710-10	1400	177	94.4	0.81	600	1.8	12000
YR710-10	1600	202	94.5	0.81	600	1.8	12500
YR710-10	1800	227	94.6	0.81	500	1.8	13000
YR800-10	2000	251	94.7	0.81	600	1.8	14500
800-10	2240	281	94.8	0.81	600	1.8	15200
800-10	2500	313	94.9	0.81	600	1.8	16000
900-10	2800	346	95.0	0.82	600	1.8	17500
900-10	3150	389	95.1	0.82	800	1.8	18000
900-10	3550	438	95.2	0.82	600	1.8	18500
900-10	4000	493	95.3	0.82	600	1.8	19000
1000-10	4500	554	95.4	0.82	600	1.8	24000
1000-10	5000	615	95.5	0.82	600	1.8	25000
1000-10	5600	688	95.6	0.82	200	1.8	26000
710-12	1120	148	03.8	0.78	500	1.8	12000
710-12	1250	165	93.9	0.78	500	1.8	13000
710-12	1400	184	94.0	0.78	500	1.8	13500
800-12	1600	210	94.1	0.78	500	1.8	14500
800-12	1800	236	94.2	0.78	500	1.8	15000
800-12	2000	262	94.3	0.78	500	1.8	15500
800-12	2240	293	94.4	0.78	500	1.8	16000
900-12	2500	323	94.5	0.79	500	1.8	17500
900-12	2800	361	94.6	0.79	500	1.8	18000
900-12	3150	406	94.7	0.79	500	1.8	19000
1000-12	3550	457	94.8	0.79	500	1.8	23000
1000-12	4000	514	94.9	0.79	500	1.8	24000
1000-12	4500	577	95.0	0.79	500	1.8	25000
1000-12	5000	641	95.1	0.79	500	1.8	26000
710-16	030	92	92.3	0.72	375	1.8	10500
710-16	710	103	92.6	0.72	375	1.8	11000
710-16	800	116	92.7	0.72	375	1.8	11500
710-16	900	130	92.8	0.72	375	1.8	12000
800-16	1000	144	92.9	0.72	375	1.8	14500
800-16	1120	161	93.0	0.72	375	1.8	15000
800-16	1250	180	93.1	0.72	375	1.8	15500
800-16	1400	201	93.2	0.72	375	1.8	16000
900-16	1600	223	93.3	0.74	375	1.8	17500
900-16	1800	251	93.4	0.74	375	1.8	18000
900-16	2000	279	93.6	0.74	375	1.8	19000
1000-16	2240	312	93.6	0.74	375	1.8	24000
1000-16	2500	347	93.7	0.74	375	1.8	25000
1000-16	2500	389	93.8	0.74	375	1.8	26000

YF series 10kV three-phase asynchronous motor technical data (design value) see

Model number	Rated power (kW)	Stator current (A)	Rated speed (r/min)	efficiency (%)	Power factor cosφ	High torque/rated torque Mmax/Min	Rotor voltage U2(V)	Rotor current l2(A)	Moment of inertia/motor kg. m²	Weight (kg)
YR450-4	315	23.4	1481	92.5	0.84	1.8	538	360	16.5	4125
YR450-4	355	26.3	1478	92.8	0.84	1.8	538	407	16.5	4180
YR450-4	400	29.2	1479	93.1	0.85	1.8	591	416	16.5	4246
YR450-4	450	32.8	1480	93.3	0.85	1.8	657	419	18.7	4422
YR450-4	500	36.3	1482	93.6	0.85	1.8	611	503	26.4	4818
YR450-4	560	40.6	1483	93.8	0.85	1.8	677	505	27.5	4862
YR500-4	630	45.4	1484	94.2	0.85	1.8	742	518	29.7	5005
YR500-4	710	51.0	1483	94.6	0.85	1.8	762	569	29.7	5170
YR500-4	800	56.7	1484	94.7	0.86	1.8	845	576	31.9	5368
YR500-4	900	63.7	1479	94.8	0.86	1.8	767	730	46.2	6765
YR500-4	1000	70.7	1482	94.9	0.86	1.8	874	703	49.5	7205
YR560-4	1120	78.2	1480	95.1	0.87	1.8	874	792	49.5	7315
YR560-4	1250	87.1	1483	95.2	0.87	1.8	1022	750	58.3	7425
YR560-4	1400	97.5	1484	95.3	0.87	1.8	1117	765	83.6	8987
YR630-4	1600	110.0	1484	95.4	0.88	1.8	1233	793	96.8	9460
YR630-4	1800	123.7	1484	95.5	0.88	1.8	1328	824	96.8	9625
YR630-4	2000	137.3	1485	95.6	0.88	1.8	1496	810	110.0	9900
YR450-6	280	21.6	983	92.2	0.81	1.8	564	306	24.2	4400
YR450-6	315	24.3	982	92.4	0.81	1.8	520	376	37.4	4565
YR450-6	355	27.3	983	92.6	0.81	1.8	568	388	40.7	4686
YR450-6	400	30.7	983	92.8	0.81	1.8	624	396	44.0	4785
YR500-6	450	34.5	981	93.1	0.81	1.8	624	449	44.0	4983
YR500-6	500	38.2	982	93.4	0.81	1.8	694	446	47.3	5060
YR500-6	560	42.6	984	93.6	0.81	1.8	779	442	50.6	5159
YR500-6	630	47.3	985	93.8	0.82	1.8	730	532	69.3	6655
YR500-6	710	53.2	986	94.0	0.82	1.8	821	531	75.9	6985
YR560-6	800	58.3	985	94.3	0.84	1.8	821	604	75.9	7205
YR560-6	900	65.5	986	94.5	0.84	1.8	934	591	80.3	7370
YR560-6	1000	71.7	987	94.7	0.85	1.8	897	684	108.9	8855
YR560-6	1120	80.2	989	94.9	0.85	1.8	1043	651	113.3	9405
YR630-6	1250	89.3	989	95.1	0.85	1.8	1137	666	124.3	9570
YR630-6	1400	99.8	990	95.3	0.85	1.8	1249	677	133.1	9900
YR630-6	1600	113.9	990	95.4	0.85	1.8	1246	685	141.9	10230
YR500-8	280	23.4	735	92.2	0.75	1.8	564	312	48.4	4895
YR500-8	315	26.3	736	92.3	0.75	1.8	619	318	50.6	4983
YR500-8	355	29.5	736	92.5	0.75	1.8	689	321	56.1	5060
YR500-8	400	33.2	734	92.8	0.75	1.8	688	366	56.1	5170
YR500-8	450	36.2	736	93.1	0.77	1.8	773	364	59.4	5280
YR500-8	500	40.2	740	93.3	0.77	1.8	881	346	85.8	6666
YR560-8	560	43.7	739	93.6	0.79	1.8	949	360	91.3	6930
YR560-8	630	49.1	739	93.8	0.79	1.8	1030	373	99.0	7194
YR560-8	710	55.2	738	94.0	0.79	1.8	1030	424	99.0	7425
YR560-8	800	62.1	741	94.2	0.79	1.8	1132	431	155.1	8800
YR630-8	900	67.1	741	94.4	0.82	1.8	1245	439	166.1	9350
YR630-8	1000	74.4	740	94.6	0.82	1.8	1245	491	166.1	9515
YR630-8	1120	83.2	741	94.8	0.82	1.8	1382	494	177.1	9845
YR500-10	250	21.9	587	91.4	0.72	1.8	536	288	53.9	4884
YR500-10	280	24.5	586	91.7	0.72	1.8	536	327	53.9	4961
YR500-10	315	27.4	585	92.1	0.72	1.8	581	339	57.2	5038
YR500-10	355	30.9	586	92.2	0.72	1.8	632	351	60.5	5148
YR560-10	400	33.8	586	92.4	0.74	1.8	690	359	63.8	5258
YR560-10	450	37.3	589	92.8	0.75	1.8	701	397	101.2	6644
YR560-10	500	41.4	590	93.0	0.75	1.8	775	396	107.8	6908
YR560-10	560	45.6	588	93.2	0.76	1.8	774	449	107.8	7172
YR560-10	630	51.2	589	93.4	0.76	1.8	868	447	117.7	7403
YR630-10	710	56.1	590	93.7	0.78	1.8	889	499	172.7	8800
YR630-10	800	63.1	591	93.8	0.78	1.8	1011	488	184.8	9328
YR630-10	900	70.9	591	93.9	0.78	1.8	1086	511	194.7	9493
YR630-10	1000	78.7	591	94.1	0.78	1.8	1179	524	212.3	9812
YR560-12	280	25	489	91.4	0.72	1.8	583	299	96.8	6545
YR560-12	315	27.6	489	91.5	0.72	1.8	635	308	104.5	6611
YR560-12	355	31.1	489	91.6	0.72	1.8	699	315	114.4	6875
YR560-12	400	34.9	490	91.8	0.72	1.8	773	319	121.0	7150
YR560-12	450	39.1	490	92.2	0.72	1.8	867	318	133.1	7370
YR630-12	500	42.8	491	92.4	0.73	1.8	774	398	172.7	8745
YR630-12	560	47.1	491	92.8	0.74	1.8	821	423	183.7	9295
YR630-12	630	52.8	491	93.1	0.74	1.8	927	418	201.3	9460
YR630-12	710	59.3	491	93.4	0.74	1.8	994	441	215.6	9790

Model	Rated power kW	Rated current A	At rated load		Synchronous speed r/min	Maximum torque/rated torque (Standard value)	weight kg
Model	Rated power kW	Rated current A	efficiency%	Power factor cosφ	Synchronous speed r/min	Maximum torque/rated torque (Standard value)	weight kg
YR710-4	2500	178	95.6	0.85	1500	1.8	12000
YR7104	2800	199	95.6	0.85	1500	1.8	12500
YR710-4	3150	224	95.7	0.85	1500	1.8	13000
YR710-4	3550	252	95.8	0.85	1500	1.8	13500
YR800-4	4000	281	95.9	0.86	1500	1.8	14500
YR800-4	4500	315	96.0	0.86	1500	1.8	15000
YR800-4	5000	350	96.1	0.86	1500	1.8	15500
YR800-4	5600	391	96.2	0.86	1500	1.8	16000
YR710-6	2000	164	95.4	0.83	1000	1.8	12500
YR710-6	2240	162	95.4	0.83	1000	1.8	13000
YR710-6	2500	164	95.5	0.83	1000	1.8	13500
YR800-6	2800	202	95.5	0.84	1000	1.8	14500
YR800-6	3150	227	95.4	0.84	1000	1.8	15000
YR800-6	3550	255	95.7	0.84	1000	1.8	16000
YR900-6	4000	287	95.8	0.84	1000	1.8	17500
YR900-6	4500	323	95.9	0.84	1000	1.8	18500
YR900-6	5000	358	96.0	0.84	1000	1.8	19000
YR710-8	1400	106	94.5	0.81	750	1.8	12500
YR710-8	1600	116	94.6	0.81	750	1.8	13000
YR710-8	1800	136	94.7	0.81	750	1.8	13500
YR710-8	2000	150	94.8	0.81	750	1.8	14500
YR800-8	2240	167	94.9	0.82	750	1.8	15000
YR800-8	2500	186	95.0	0.82	750	1.8	15500
YR800-8	2800	205	95.1	0.82	750	1.8	16000
YR900-8	3150	233	95.2	0.82	750	1.8	18000
YR900-8	3550	260	95.3	0.83	750	1.8	19000
YR1000-8	4000	292	95.4	0.83	750	1.8	21000
YR1000-8	4500	328	95.5	0.83	750	1.8	22000
YR1000-8	5000	364	95.6	0.83	750	1.8	23000
YR710-10	1120	89	94.1	0.79	600	1.8	12000
YR710-10	1250	97	94.2	0.79	600	1.8	12500
YR710-10	1400	109	94.3	0.79	600	1.8	13000
YR710-10	1600	124	94.3	0.79	600	1.8	13500
YR800-10	1800	136	94.5	0.80	600	1.8	14000
YR800-10	2000	151	94.6	0.80	600	1.8	15000
YR800-10	2240	168	94.7	0.80	600	1.8	16000
YR900-10	2500	191	94.6	0.80	600	1.8	18000
YR900-10	2800	214	94.7	0.80	600	1.8	19000
YR1000-10	3150	237	94.8	0.81	600	1.8	22000
YR1000-10	3550	267	94.9	0.81	600	1.8	23000
YR710-12	900	76	93.2	0.74	500	1.8	12500
YR710-12	1000	84	93.3	0.74	500	1.8	13000
YR710-12	1120	94	93.4	0.74	500	1.8	13500
YR800-12	1250	103	93.5	0.75	500	1.8	14000
YR800-12	1450	116	93.6	0.75	500	1.8	15000
YR800-12	1600	132	93.7	0.75	500	1.8	16000
YR900-12	1600	130	93.8	0.76	500	1.8	17000
YR900-12	1800	146	93.9	0.76	500	1.8	17500
YR900-12	2000	162	94.0	0.76	500	1.8	18500
YR900-12	2240	169	94.1	0.76	500	1.8	19000
YR1000-12	2500	199	94.2	0.78	500	1.8	21000
YR1000-12	2800	223	94.3	0.78	500	1.8	22000
YR1000-12	3150	247	94.4	0.78	500	1.8	23000
YR1000-12	3550	278	94.5	0.78	500	1.8	24000

Production environment

Wound induction motor Manufacturer

As one of China professional large electric motor manufacturers, we focus on providing high-quality wound induction motor and excellent service since 2003. We are a professional manufacturer and factory of 65,000 M² which mainly produce hv motors, ex proof motor, pmsm motor products for around 20 years’ experience. We provide you with large electric motors wholesale, customization, design, packaging, industry solutions and OEM & ODM service.

If you have any questions about wound induction motor, motor wound, wound round motor,wound type motor, please don't hesitate to contact us at any time. We will provide detailed information and technical support about the features, specifications, solutions and customization options of hv motors, ex proof motor, pmsm motor... Welcome you to visit our factory!
